MODEL TL-2186

International size reference : ER22G68


TECHNICAL DATA

(Typical Values @+25'C for batteries stored for one year or less)

Nominal capacity @ 0.5mA, TO 2V 0.4Ah
Rated voltage 3.6V
Maximum continuous current 5mA
Maximum pulse current capability 10mA
Rated 1 sec. pulse capability (to 3V) 5mA
Weight 5.3g (0.187oz.)
Operating temperature range -55'C to +75'C
U.L. Component recognition MH 12193


AVAILABLE TERMINATION
SUFFIX- /P TINNED NICKEL PINS



Note: Any representations in this website concerning performance, are for informational purposes only and are not
construed as warranties either expressed or implied, of future performance.
